72′ Ocean Alexander Pilothouse 2014 “Cirrus”

  • SEATTLE, WA
  • SOLD
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”
72′ Ocean Alexander Pilothouse 2014 “Cirrus”

Description & Details

The 72 Pilothouse from Ocean Alexander. More beam. More living options. A more modern hull that gives you better speed with less fuel burn. The 72 Pilothouse is a take on an Ocean Alexander classic. OA’s continuing obsession with engineering, safety and performance is evident all over it. They’ve added some intriguing designs features such as a private staircase entry to your master stateroom, an island galley layout and full wet bar with seating in the spacious command bridge area. Welcome and enjoy!

Highlighted Details & Specifications

Construction
  • Vinylester resin infusion hull, deck, bulkheads and floor construction
  • Reinforced collision bulkhead
  • 2″ elliptical 316L stainless steel handrails and stations. 1 1/2″ on the FB.
  • Sound dampening to the level of 1/2 to 1/10 of ISO-6954 sound level ratings
  • Exterior painted surface, with professional grade Alexseal polyurethane paint for minimal maintenance.
  • Marine grade aluminum structural beams integrated into the hull and deck.
  • Cross-knit directional carbon fiber added in high stress areas for integrity and torsional strength.
  • • Solid hull bottom
  • • Three coats of Seahawk hi-build epoxy barrier coat under the bottom paint.
  • Show more
Mechanical
  • Twin CAT C18 1150 hp engines. (approx. 320 hrs)
  • Three control stations, aft deck docking, lower helm and FB helm.
  • Yacht Controller
  • Electronic engine controls
  • Delta-T intake/exhaust fans with de-mister.
  • PTO hydraulic take-off on each transmission for powering the thrusters, stabilizers and windlass.
  • Monolithic S/S engine beds for added stability and strength.
  • S/S hand rails in engine room,
  • Military spec A16XN alloys used in engine exhaust system for optimum performance.
  • Kohler 23 kW genset(s) (approx. 346 hrs stbd – 369 hrs port)
  • S/S rudders
  • Oversized bronze propellor shaft V-struts.
  • Dripless shaft and rude seals.
  • High performance computer designed and machined propellors.ual
  • 1 ea. Stidd helm chair PH
  • 2 ea. Stidd helm chairs on FB
  • Muir VWCLP3500 hydraulic windlass.
  • S/S anchor with all chain rode.
  • Chain counter at PH and FB helm.
  • Ocean Alexander proprietary “dry bilge ventilation system” with dedicated exhaust to keep bilges dry and mildew free.
  • Steelhead 1500lb hydraulic/electric davit w/power rotation.
  • Fire extinguishing system in engine room.
  • Pantograph windshield wipers w/washers and intermittent function.
  • Kahlenberg HD horn system
  • Ocean Alexander designed oversized shafts, rudders and other drive train systems are one class larger than the competitive vessel.
  • Show more
Plumbing
  • 2mm thich 316 S/S water tank w/sight gauge.
  • Fresh water wash down at the bow, the stern and the boat deck.
  • Dockside water connection.
  • One 40 gallon water heater w/dual heating elements for faster heating.
  • 4.5mm 5052 aluminum fuel g=tanks w/sight gauges, tested to 33CFR510 international standards.
  • High and low fuel alarm system.
  • Dual Racor fuel/water separator w/Y-valves for engine and generator
  • Filler for fuel tanks on both port and stud side, so complete fueling can be done from either side of the vessel
  • Fuel system with venting and “catch” system, designed for burps, etc.
  • Common drainage system
  • Automatic bilge pump(s) with high water alarms
  • Dry bilge area arrangement in the center of the engine room
  • Show more
Electrical
  • Garmin 8617 series screens with 3 ea. screens at the PH helm and 2 ea. screens at the FB helm. (new summer 2017)
  • Garmin HD 6′ 6kW open array radar
  • Furuno auto pilot
  • ICOM VHF radio 2 ea.
  • Garmin GSD25 black box sounder
  • Garmin Panpotix w/PS51 transducer for fwd looking sonar
  • Garmin GT41 CHIRP transducer
  • Garmin AIS600 with NMEA GPS
  • Engine room and aft deck camera system
  • Triband Sat HD7 w/DirectTV receivers
  • Ritchie Compass 4 1/2″
  • Maretron system w/”anchor watch” remote panel in the master cabin
  • Show more
Battery
  • HD sealed AGM batteries = 4 ea. 24vdc engine start, 2 ea. 12vdc gen set start, 3000 amp hours of inverter/house 24 vdc bank.
  • Battery paralleling system with controller switch
  • Service battery switch
  • Engine battery isolation switch. AC/DC System:
  • AC outlets
  • AC/DC distribution panels w/magnetic circuit breakers
  • 60 amp battery charger for house and engine start bank(s)
  • Iso-Boost package for both shore power cords
  • Shore power receptacles w/Iso-Boost and 2 ea. 50/240amp power cords w/ Glendinning cable master cord reels.
  • Electrical breaker panels with backlighting.
  • 24v LED lighting. Some w/dimming function
  • Dometic reverse cycle air conditioning rated for “Extreme Tropical Climates”.
  • Refrigerant type is accepted worldwide under the Montreal Protocols.
  • Vimar switches and outlets
  • Show more
Accommodations/Interior, Audio/Video SALON
  • LED 46″ TV with A/V system
  • One sub-woofer
  • Evan K. Marshall custom design salon furniture and sofa. Sofa includes storage.
  • Wood valances
  • 24V LED lights
  • Enlarged windows in salon with custom engineered solution incorporated marine grade aluminum beams allowing for industry leading window expanse.
  • Show more
MASTER CABIN
  • LED 40″ TV
  • DVD/CD audio stereo and video system • One sub-woofer
  • King bed w/custom mattress
  • Head board
  • Two nightstands
  • Storage under bert
  • Chest of drawers• Ensuite head w/stall shower
  • Safe in hanging locker
  • Cedar lined hanging lockers
  • Enlarged “gill” style windows w/ custom engineered “sandwiched glass” construction
  • Show more
GENERAL CABIN/HEAD FEATURES
  • Fresh Air system w/filtered fresh air drawn from outside and vented to the lowercabins for constant fresh, clear air distribution
  • China sinks
  • Grohe fixtures
  • Seamless fiberglass shower designs
  • Planus toilet systems
  • Granite/marble in shower, floors, seats, trim.
  • VIP cabin w/ensuite head and entertainment system
  • Port Guest cabin with ensuite head and entertainment system
  • Side by side Maytag washer dryer units
  • USB power plugs at PH helm and master cabin
  • Custom decor, bed spreads, curtain fabrics, soft goods, etc.
  • Complete dishwater and flatware package
  • Complete galley cookware
  • Carbon monoxide and smoke detectors
  • Satin varnish on interior wood work
  • Complete mooring pkg.
  • 6 person lift raft on boat deck
  • Show more
GALLEY
  • Galley see-through to salon
  • Granite countertops
  • Solid wood floor custom engineered with same wear capacity as a solid 3/4″ wood floor.
  • Large single bowl Franke sink
  • 36″ JennAir refer/freezer
  • 30″ JennAir over the range Microwave/Convection oven
  • 30″ JennAir 220v cooktop
  • Garbage compactor
  • 2 ea. Fisher-Pykel dishwashers drawers
  • Show more
CREW CABIN/ MISCELLANEOUS
  • Stall shower
  • Enclosed head
  • Tilt down oversized custom berth
  • Storage lockers
Electronics
  • Complete new Garmin Suite (summer 2017)
  • 3 ea. 8617 17″ screens at the lower helm and 2 ea. 8617 17″ screen on the CB
  • 2 ea. ICOM VHF’s w/ command mics for CB
  • Furuno auto pilot
  • Martron system w/master cabin anchor watch
  • Garmin Panoptix PS51 transducer for forward looking sonar
  • Garmin GT41CHIRP transducers aft
  • Garmin 626 x HD2 6kW 6′ open array
  • Garmin AIS600 transponder and NMEA GPS
  • Camera system (engine room and aft deck)
  • KVH M7 Sat TV antenna w/Direct TV receivers
  • Ritchie compass (2 ea.)
  • Show more
Mechanical
  • Twin C-18 CATS 1150 hp (320 hrs) (last service 4/17 at 290 hrs)
  • 2 ea. Kohler 23 kW generators (P-369 hrs. S-344 hrs)
  • Spare parts and filters
  • 900 god Sea Recovery water maker
  • 25 hp hydraulic bow thruster
  • 15 hp hydraulic stern thruster
  • Bow and stern thruster proportional controller with locking (3 ea. station)
  • Yacht Controller
  • WesMar stabilizer system
  • Show more
