Description & Details

The high performance patented Stepped ‘V Ventilated Tunnel (SVVT) was developed by Michael Peters. The SVVT hull form incorporates a classic deep ‘V’ hull with two transverse steps and a central tunnel aft. Unique to other current stepped deep ‘V’s, is the central tunnel aft, which is the key attribute to its performance. The shallow tunnel serves to increase the longitudinal stability of the boat in high speed turns and adverse situations.

The tunnel creates lateral area and carries a channel of water that controls the aft end of the boat and keeps it from spinning out of control. Combined with the reduced wetted surface created by the transverse steps, the tunnel ventilates with air and clears our at high speed, further reducing drag. The combination of deep ‘V’, steps and ventilated aft tunnel add up to being the most efficient high speed rough water hull form developed today. Application of the SVVT hull to the Verve 47 represents the merging of advanced hull forms with advanced outboard engine power and advanced styling and concept design. The combination of technologies culminates in the fastest, best riding and most maneuverable boat in its class and represents the largest and grandest SVVT pleasure boat built today.


Azimut Verve 47
Azimut Verve 47
Azimut Verve 47

Highlighted Details & Specifications

Hard Top
  • Carbon fiber Hard Top equipped with:
  • Lights mast
  • Compliant navigation lights
  • Electric adjustable spot with remote
  • control (for USA version)
  • Portlight with manual opening system
  • Show more
  • Chain locker provided with drainage, accessible through hatch
  • Remote control for fore winch
  • Stainless steel anchor line anti-rubbing
  • protection
  • Hatch (emergency exit from master
  • cabin)
  • Sunbed area with built-in glass holders
  • Grabrails on sunbed area sides
  • C-shaped seating area at the bow
  • Fridge
  • Scuppers
  • Show more
Walk Arounds
  • Access to port walk around from the
  • cockpit
  • Access to starboard walk around from
  • the wheelhouse
  • Rubber rub-rail with stainless steel insert
  • Stainless steel pulpit with handrail
  • Show more
  • One access on port side through stainless steel gate
  • Port side platform with electric control
  • Manual pull-out swimming ladder, located inside the side platform
  • "L" shaped sofa in dining area
  • Cabinet installed crossways, aft of the
  • wheelhouse, with:
  • - Icemaker
  • - Fridge
  • Engine room access, through hatch located at the center of the cockpit
  • Anti-slip on GRP floor
  • Lighting with LED spotlights and bars
  • and mounted recessed on the fabricupholstered ceiling by means of a stainless steel frame
  • Scuppers
  • Show more
Aft Platform and Hold
  • Hold possibly to be used as a garage for
  • seabob, equipped with manual hatch
  • PVC and stainless steel rub-rail
  • Anti-slip on GRP floor
  • Extractable shower head
  • Port side external GRP step for access to
  • the cockpit
  • One aft gate
  • Show more
  • The wheelhouse is located at the center; it is accessible from starboard side, through the starboard walk around, or from port side through
  • the aft gate and the cockpit, or through the port
  • walk around.
  • In includes:
  • Commander seating area with electric
  • adjustments
  • Co-pilot seating area on left and right
  • sides of the commander
  • Leather-covered steering wheel
  • Dashboard including the following controls:
  • - magnetic compass
  • - 7" Vessel view Mercury display
  • - electronic navigation instruments,
  • BRONZE version (*)
  • - VHF communication system (for USA
  • version)
  • - audible alarm controls
  • - windscreen wiper control
  • - USB socket
  • Dedicated lighting
  • Adjustable air conditioning outlets
  • Show more
Dinette / Galley
  • Located amidships, full-beam, it is the space
  • that connects the master and guest cabins, the
  • head, and, through the manual sliding hatch,
  • the exterior.
  • It is essentially composed of:
  • "L" shaped three seater sofa, placed longitudinally on port side
  • Table with fixed stainless steel base and
  • HPL plane
  • Household appliances:
  • - induction type range
  • - fridge/freezer
  • - microwave oven + grill
  • Carpeted floor
  • Port and starboard windows with builtin portlight, with curtain
  • TV pre-installation above galley cabinet
  • LED technology spotlights
  • LED courtesy lighting under the steps
  • Sockets
  • Show more
Master Cabin
  • Located at the bow, it is composed of:
  • Wooden access door
  • Double bed with large locker underneath
  • Mattress, pillows and bedspread
  • Leather-coated headboard
  • Two reading lights
  • Two bedside tables
  • One wardrobe column on starboard side
  • with hanger bars and external mirror
  • One column on port side with external
  • mirror
  • Carpeted floor
  • Two windows with built-in portlights on
  • port and starboard sides, with curtains
  • Lighting with spotlights on
  • leather-upholstered ceiling
  • Sockets
  • Hatch for escape way on fore deck
  • Show more
Guest Cabin
  • Located abaft the dinette, it is composed of:
  • Wooden access door
  • Two fixed single beds with system to
  • transform them into a double bed
  • One storage located under the two beds
  • Mattresses, pillows
  • Leather-coated single headboard
  • Two reading lights
  • One bedside table between the beds
  • One wardrobe on starboard side
  • Carpeted floor
  • One side window with curtain
  • LED technology spotlights
  • Sockets
  • Show more
  • Located on starboard side, it is composed of:
  • Access from dinette through wooden
  • door
  • Washbasin on the top in HPL
  • Faucets
  • Storage under the washbasin
  • Mirror above the washbasin
  • Toilet
  • Shower enclosure with:
  • - glass access door and aluminum frame
  • - GRP shower enclosure walls and
  • painted insert
  • - tilting seating area
  • - GRP non-slip floor
  • - mixer tap
  • - hand-held and ceiling-mounted shower
  • head
  • - lighting on ceiling
  • Laminated floor
  • Side windows with recessed portlight,
  • provided with curtain
  • Head accessories
  • Lighting on ceiling
  • Socket
  • Show more
Electrical System
  • Main characteristics:
  • Shore-powered power supply
  • Electric panels for systems area:
  • - one main panel 12/24 V DC, located aft
  • of the petrol tank, in the engine room
  • - one shore differential panel 230 V AC
  • located in the cockpit locker
  • Electric panels in cabins area:
  • - one main panel 230 V AC for power circuit breakers, located in technical storage and accessible from guest cabin (aft,
  • starboard)
  • - one distribution panel 230 V AC – 24
  • V DC, located in storage, on port side of
  • the access to the dinette from outside
  • Onboard voltages:
  • - 230 V - 50 Hz AC STD
  • - 24 V DC from battery set
  • - 12 V DC from battery set and AC/DC
  • voltage reducer
  • Generator (for USA version):
  • One 14 KW / 60 Hz generator with ignition protected kit
  • Show more
Shore Power Sockets
  • EU one 230 V AC - 50 A socket
  • The AC power sources terminate on the
  • main electric panel in the engine room,
  • for the 230 V network. The AC power
  • sources are protected by suitably sized
  • fuses, and introduced into the network
  • by means of remote control switches
  • Show more
  • Four engine batteries 12 V – 90 Ah
  • Four service batteries 12 V – 90 Ah
  • One 12 V - 70 Ah battery for generator
  • (for USA version)
  • Two 12 V – 25 A engine generators (one
  • of which charges also the generator)
  • One 24 V – 60 A service battery charger
  • Show more
Lights and Sockets
  • 230 V AC sockets for main utility power
  • supply, EU type
  • USB sockets
  • Internal lighting: 24 V LED type
  • External lighting: 24 V LED type
  • Four V8 MERCURY outboard engines, 450 hp
  • each
  • STD (BRONZE) electronic navigation instruments
  • For a detailed list of alternative/additional equipment available, please refer to the Optionals
  • price list.
  • Show more
Fuel System
  • One petrol tank, made in aluminum, installed transversally in the engine room,
  • total 2340 l (618.2
  • One electronic fuel level sensor monitored through indication on the wheelhouse
  • One visual level gage
  • Four engine filters
  • One tank vent
  • Remote petrol shut off from tank to
  • engine through solenoid valves
  • Refueling on deck, starboard side
  • Show more
Diesel System For Generator (For USA Version)
  • One 150 l (39.6 diesel tank,
  • in aluminum, located forward of the service compartment, at the center, under
  • the petrol tank
  • Two fuel level sensors for local monitoring and remote monitoring from the
  • wheelhouse
  • Manual valve and RACOR 120 pre-filter
  • on fuel delivery line to generator
  • Manual valve on fuel return line from
  • generator
  • One tank discharge on starboard bulwark, with siphon
  • Refilling through a filler cap located aft
  • of the starboard bulwark
  • Show more
Bilge System
  • Main system composed of two automatic and independent pumps located
  • in each watertight compartment:
  • - one in engine room
  • - one (central) in the locker under the
  • guest cabin floor (aft cabin)
  • Secondary or auxiliary system composed
  • of a manual bilge pump, whose control
  • is located inside the locker on port side
  • forward of the cockpit which allows,
  • through a switch, to suck from the zone
  • under the guest cabin bed or from the
  • service compartment.
  • Show more
Fresh Water System
  • 300 l (79.3 plastic fresh water
  • tank in technical locker, under the galley
  • dinette floor
  • Water refilling through opening in central part of starboard walk around
  • Water pressure pump unit (24 V) located
  • in the engine room, starboard side, with
  • electronic control
  • 40 liter (10.6 water heater
  • - 230 V - 50 Hz AC - located under the
  • dinette/galley floor
  • Fresh water toilet flushing
  • System that can be isolated by ACORN
  • manifolds located on starboard side at
  • the head bulwark
  • Show more
Black Water System
  • One TECMA toilet
  • One 106 l (28 Dometic tank
  • with built-in pump, located in the engine
  • room
Gray Water System
  • 9 l (2.4 plastic collection tray,
  • located under the guest cabin floor
  • One outboard discharge pump
  • Two air conditioning condense collection trays under the dinette/galley floor
  • and under the guest cabin floor (together
  • with the air conditioning system – USA
  • version)
  • Show more
Ventilation/ Extraction
  • One extractor located in the engine
  • room, port side, approx. 7.2 m3
  • /min (254.27 cu.ft/min) connected to the
  • outside through ø 100 mm (3.94 in)
  • pipe. The air intake is from starboard
  • side through an opening provided with
  • water separator
  • Show more
Air Conditioning System (For USA Version)
  • Power supply from onboard generator or
  • from shore
  • One dedicated seawater electric pump
  • with relevant seawater intake installed
  • in the service compartment
  • Distribution:
  • - Dinette/Galley and Guest cabin: 12000
  • BTU
  • - Master cabin: 6000 BTU
  • - Wheelhouse: 8000 BTU
  • Temperature control panel for each air
  • conditioning unit
  • Sea outlet for water used for air conditioning
  • Two condense collection trays with vent
  • and pump for outboard discharge (see
  • "gray water system")
  • Show more
Other Systems
  • Trim tabs: The automatic trim tabs system includes two Zipwake, one on port
  • side and one on starboard side, size approx. 450 mm (18 in). The control and
  • setting/adjustment panel is located in
  • the wheelhouse
  • Engine room dry chemical fire
  • extinguishing system with manual
  • control
  • Carbon monoxide detection system
  • composed of three sensor located
  • in Master cabin, Guest cabin and
  • Dinette/Galley (for USA version)
  • Show more
  • One telescopic boat hook
  • Two mooring lines
  • Fender lines: 18 m (59'1'')
  • Six fenders
  • Six black fender covers
  • One Owner's manual
  • One wooden boat model
  • Two floating keyrings
  • One large bag with logo for manuals
  • One remote control holder with logo
  • Show more
